Single Body
Standard
Torsion
Engineered to store and release rotational energy. Our standard single-body torsion springs offer precise torque delivery and excellent fatigue resistance. Manufactured using advanced CNC wire forming technology to ensure exact leg alignment and angular force for a wide variety of industrial and consumer mechanisms.
Technical Specifications
Standard manufacturing parameters for rotational force applications.
| Parameter | Specification Range | Standard Tolerance |
|---|---|---|
| Wire Diameter (d) | 0.3 mm - 10.0 mm | ± 0.01 mm - ± 0.04 mm |
| Outer Diameter (OD) | 5.0 mm - 60.0 mm | ± 0.1 mm - ± 0.5 mm |
| Torque Capacity | 0.5 Nm - 50 Nm | ± 10% (Tighter tolerances available) |
| Leg Angles | Customizable (e.g., 90°, 180°, 270°, 360° or exact degrees) | |
| Available Materials | Music Wire, Stainless Steel (302/304/316), Phosphor Bronze, Hard Drawn Steel | |
Features & Advantages
Consistent rotational performance for dynamic mechanisms.
Advanced multi-axis CNC coiling ensures the exact free angle between legs is maintained across high-volume production runs.
Engineered with calculated inner diameters to prevent binding when the spring body reduces in size during rotational deflection.
Manufactured using premium grade wire and optimized coil pitches to eliminate destructive friction between adjacent coils.
Custom leg lengths and bend configurations available to secure perfectly onto your specific shafts or anchoring points.
Common Applications
Providing essential rotational return force across industries.
Hinges & Lids
Providing counterbalance and return force for doors, covers, and access panels.
Levers & Switches
Ensuring reliable rotational return in mechanical controls and electrical switchgear.
Clamping Tools
Standard gripping force applications in household and industrial clamping mechanisms.
Automotive Components
Used in seatbelt mechanisms, trunk latches, and transmission assemblies.
Ready to Optimize Your Manufacturing?
Send us your CAD files, blueprints, or performance requirements. Our engineering team will provide a comprehensive DFM (Design for Manufacturability) analysis and quote within 24 hours.
